4G OBD with BLE

4G- D218

4G- D218 is an intelligent on-board diagnostic device compatible with passenger and commercial vehicles, it features plug-and-play technology, could read diagnostic info from vehicle ECU and capture location data, then send them to backend server for real-time remote diagnostic and tracking purpose.

Get A Free Quote

Buy It Now

Products Categories

OBD II

T-BOX (ELD)

GPS TRACKER

ASSET TRACKER

DASHCAM

PERSONAL TRACKER

ACCESSORIES

Get A Free Quote

PC tool configuration
Real-time tracking
OBD protocols
Plug-and-Play
DTC (error code)
Fuel consumption statistics
Regular G-sensor data reporting
Unplug alarm
Remotely cut off engine
Bring BLE

Mechanical	Size	63mm (L) x 48mm (W) x 28mm (H)
Mechanical	Weight	50g
Interface		OBD interface: 16 pin standard OBD II
		Conﬁguration interface: Micro-USB
		SIM card interface: Micro SIM, Push-Push Type
Data transmission		Packet data (LTE) and SMS
Positioning method		GPS
Storage		2MB FLASH
OBD protocol		ISO 9141-2
		ISO 14230-4
		ISO 15765-4
		SAE J1939
		SAE J1587/J1708
Power	Working Voltage	9-36VDC
	Working Current	Max.: <[email protected]/27.6VDC
		Average: <[email protected]/27.6VDC
		Sleep mode: <10mA@12/24VDC
GNSS		Channels: 66
		Sensitivity: -165dBm
		Accuracy: 5m CEP
		Time to ﬁrst ﬁx:
		Cold start: <30s (typ.)
		Hot start: <1s (typ.)
Cellular		Frequency (D-218L):
		LTE-FDD: B2/B4/B5/B12/B13/B25/B26;
		WCDMA: B2/B4/B5
		Data:
		LTE (Mbps): Max. 10 (DL)/ Max. 5 (UL)
		DC-HSPA+ (Mbps) : Max. 42 (DL)/Max. 5.76 (UL)
		WCDMA (Kbps) : Max. 384 (DL)/Max. 384 (UL)
		EDGE (Kbps) : Max. 296 (DL)/Max. 236.8 (UL)
		GPRS (Kbps) : Max. 107(DL)/Max. 85.6 (UL)
		Network protocol: Embedded TCP/IP stack
3-axis accelerometerk		Driving behavior detection
LED Indication		GPS/Cellular/OBD indication
Antenna	Cellular	Internal
	GPS	Internal

Accessories		OBD II extension cable
		9-Pin deutsch wiring harness
		6-Pin deutsch wiring harness
		Power cable
Environment	Working Temperature	-30℃ ~ +70℃
	Storage Temperature	-40℃ ~ +85℃
	Humidity	5%～95%（no fog）
